Why Choose Ramsay Welding?

Wide Range of Expertise in Metal Forming, Machining, Fabrication, & Welding

Facilities List

About Our Facility And Equipment

Ramsay Welding has a wide range of cutting, forming, machining, welding, punching, and other metalworking equipment. With a 12,000 sq. ft. facility located in Woburn, MA, we serve New England locations of large multinational customers and many other local companies throughout New England. Every project is managed professionally with the expertise and timeliness that we pride ourselves on.

Features

  • 12,000 sq. ft. Facility
  • Most Advanced Equipment in the Industry
  • Solar Powered
Ramsay Building

Metal Fabrication Equipment

Welding Equipment

  • 2 – Miller Dynasty 700 AMP TIG welding machine
  • 2 – Miller Dynasty 350 AMP TIG welding machine
  • 4 – Miller Syncrowave 350 AMP TIG welding machines
  • 3 – Miller MIG welders on carts up to 600AMP
  • 1 – Lincoln Push/Pull MIG welder for aluminum.
  • 5 – Precision Machined (Siegmund) Layout and fabrication tables to 5’ x 10’

Cutting Capacities

Shearing

  • 3/8″ Steel, 1/4″ Stainless, 3/4″ Aluminum

Saws

  • 1 – Marvel #8 Mark III, 18″ x 20″ Vertical Mitering Saw with Tiger Stop Gage
  • DoAll 36″ throat band saw for hand cutting of shaped pieces.
  • 10″ Delta table saw, 5 HP for cutting and beveling

Laser Cutting

  • Amada 4000 Watt Laser – 5’ x 10’ Bed – Cutting capacities of 7/8” Steel, ½” Stainless Steel and 3/8” Aluminum

  • Amada 4000 Watt Laser with Rotary Indexer for cutting round and square tubes and pipe up to 8″

Water Jet Cutting

  • Flow Water Jet – with 48” x 96” Cutting area

Forming and Rolling Equipment

Press Brakes

  • 1 – Amada 137 Ton 6 Axis CNC x 10’ Long Brake

  • 1 – LVD 330 Ton – 3 Axis CNC x 13’ Long Brake

  • 1 – Chicago 600 Ton x 14′ Long Brake – Bending up to 1” thick

  • 1 – Diarco 35 Ton x 6’ Long Brake

Rolling Equipment

  • Davi MCA2527 4 Roll CNC Plate Roll , 10 1/2” top roll Dia. x 8’ Long
  • FAMAR Pinch rolls, 4 ¾” Top Roll Dia. x 5’ Long
  • Tennsmith Pinch Rolls, 3” Top Roll Dia. x 4’ Long
  • Misc. Pinch Rolls down to 1 ½” Top Roll Diameter

Angle, Bar & Tube Rolls

  • Comac 303 2” x 2” x ¼” Angle up to 1 ½” Pipe, 3/8” x 2” Hard Way
  • Comac 307 4” x 4” x ½” Angle up to 4” Pipe, 1” x 4” Hard Way
  • Baileigh RDB-325 Programmable Rotary Draw Bender, up to 2” Sch 80 Pipe. Square and Round tube, including solid bar

Machining Equipment

Millers & Lathes

  • Haas VF11 milling machine 120” x 40” x 30” travel – 3 Axis control CNC milling with indexable rotary table
  • Haas VF3-YSS milling machine 40” x 27” x 30” travel – super speed, thru spindle coolant
  • Bridgeport Series I, 9″ x 45″ table, 2 HP with 3 Axis D.R.O.
  • Chevalier CNC Toolmakers/Engine Lathe – 40” x 18” Diameter max.

Measuring/Testing Equipment

  • Tesa Height Gauge – 24” Microhite 600 with printer
  • Mitutoyo Calibration Master .2000-12.2000
  • Plug & Pin Gage Sets – round & rectangular
  • Starrett Surface Plate Ola 36” x 48” x 8”

Other Equipment

  • Numerous welding positioners 200 Lb. to 2,000 Lb.
  • Cranes and Forklifts to 6,000 Lbs.
  • 36″ x 48″ Surface Block
  • 5 – Siegmund precision machined layout and fabrication tables to 5’ x 10’
  • 6 – Acorn layout and fabrication tables
  • 5’ W x 6’ H x 8’ Deep 650° F preheat & annealing oven
  • Plasma & oxyacetelyne cutting outfits
  • Haeger PEM Inserter 8 Ton x 24” Deep
  • Radius Corner Notcher – 1/8” to 1” Radius

Metal Fabrication Equipment

Welding

  • 8 Miller Syncrowave 300 AC/DC TIG Welding Machines
  • 3 Miller MIG Welders on Roll-Arounds Carts
  • 1 Miller 600 Amp AC Power Source
  • 1 Lincoln MIG Welder with Push-Pull for Welding Aluminum
  • Jetline Seam Welder, 0.010” to 0.187” Thick x 55” Long Material Capacity, from 2.50” DIA to 60” DIA with Pulse Arc Controller
  • Numerous Welding Positioners, 50 lbs. to 2,000 lbs.

Cutting

Shearing

  • 10’ Darley Shear – Capable of Shearing up to 1/4” Stainless Steel & 3/8” Steel

Saws

  • Marvel #8 Mark III, 18” x 20” Capacity with Automatic Feeds & Accurate Mitering
  • DoAll 36” Throat Band Saw for Hand-Cutting Shaped Pieces
  • 10” Delta Table Saw, 5 HP for Cutting & Beveling Nonferrous Metals

Punching & Drilling

Punch

  • CNC Strippit 750, 44-Ton, 30” x 72” XY-Axis with Up to 3/8” Thick Material
  • Geka Hydracrop #110AD Hydraulic Ironworker 120-Ton

Drill

  • 48” x 11” Radial Arm Saw, 3” Capacity
  • 1/2” Multi-Speed Drill Press

Rolling

  • Angle Bar & Tube Rolling on Bullnose Rollers

Plate Rolls

  • Davi – 5/8” Thick Up to 6’ Long, Up to 1” Thick, Dependent on Length
  • 1/4” Plate to 6’ Long – 3/4” Plate to 2’ Long
  • Pexto Rolls – 4’ Long with 3” Diameter Top Roll

Forming and Rolling Equipment

Press Brakes

  • 330-Ton LVD – 2-Axis CNC Control 13’ Bed
  • 600-Ton Chicago – Capable of Bending 5/8” Plate to 14’, 3/4” Plate to 10’, 1” Plate to 8’, Up to 2” Thick
  • 35-Ton DiAcro Brake – 5’ Long

Milling

  • Haas Large VF-11 CNC Machining Center XYZ-Axis of 120″ x 40″ x 32″
  • Bridgeport Series I, 3-Axis DRO

Machining Equipment

Millers & Lathes

  • Haas Large VF-11 CNC Machining Center XYZ-Axis of 120″ x 40″ x 32″
  • Bridgeport Series I, 3-Axis DRO

Other Equipment

  • Numerous Welding Positioners, 50 lbs. to 2,000 lbs.
  • Cranes & Forklifts to 6,000 lbs.
  • 36” x 48” Surface Block
  • 8 Acorn Layout & Fabrication Tables
  • 48″ x 48″ x 60″, 1,000 °F. Preheat & Annealing Oven, Plasma & Oxyacetylene Cutting
  • Haeger PEM Inserter
  • Radius Corner Notcher – 1/8” to 1” Radius
